2 Hour Fire Resistant Door

Description

News of fire in high rise building in major cities in Malaysia are rare. But that doesn’t meant that you should take fire safety for granted, particularly if you’re in charge of managing a high rise building. Not only are fire escapes route must be unobstructed, but the right fire rated door shall be installed.

Stairways is an important escape path in fire but it can be block with fire and smoke if a 2 hour fire rated door is not installed in place. This is the minimum requirement for all vertical openings in building like stairway or communication risers to prevent fire from spreading quickly.

It is important that you purchase 2 hour fire rated door from a certified fire rated door supplier in Malaysia. Be sure to check out that the door complies with the latest Malaysian industry standard and Bomba to ensure the safety of your occupants are not compromised.

Your fire rated door supplier in Malaysia will also advise the right way to install the fire door properly to ensure it is functional during a fire breakout. This includes that the fire door is always closed, or held open in compliant electromagnetic device that release during a fire. This helps you to prevent risking your buildings occupants safety at all time.

All size mentioned above is outer frame size
For customize fire door set
1) Door Frame Size

Thick – 140mm / 150mm (standard wall size)

Width – Single leaf up to 1200mm / Double leaf up to 2400mm

Height – Up to 2400mm

2) Door Frame Material Selection

1.2mm electro-galvanized metal door frame

3) Door Frame Rebated Type (Profile)

A)   Single Rebated

B)   Double Rebated

C)   Shadow Gap (for metal frame only)

Note : Standard rebated size for fire door = 52mm

Door frame profile size can be customized

4) Door Frame Finishes

A)   Paint





For customize fire door set
1) Door Size

Thickness – 52mm

Width – Single leaf up to 1200mm / Double leaf up to 2400mm (refer to door frame size)

Height – Up to 2400mm (refer to door frame size)

2) Door Finishes

A) High Pressure Laminate

B) Veneer with Lacquer / Shellac finish

C) Paint

3) Door Edging / Meeting Stiles

1.0mm Metal Capping

All ironmongery included in fire door set
Single leaf fire resistant door
  • NB Lever Handle
  • Entrance Mortise Lock / Mortise Passage Lock
  • 75mm Euro profile Thumbturn  Cylinder
  • Molicc 5″ Hinge
  • NB Door Closer
Double leaf fire resistant door
  • NB Lever Handle
  • Entrance Mortise Lock / Mortise Passage Lock
  • 75mm Euro profile Thumbturn  Cylinder
  • Molicc 5″ Hinge
  • NB Door Closer
  • Door Selector / Door Coordinator
  • Auto Bolt with dust cover
Additional
  • Door Stopper
